Silicon Semiconductors

Click here to go to our main page on microwave semiconductor technologies

Click here to go to our page on antimonide-based compound semiconductors

Click here to go to our page on gallium arsenide semiconductors

Click here to go to our page on gallium nitride semiconductors

Click here to go to our page on indium phosphide semiconductors

New for August 2009! We've split our page on microwave semiconductor technologies page into multiple pages.

Silicon is the "army of ants", to quote Professor Hajimiri!

Silicon is so cheap you could shingle your roof from it, and maybe some day you will, in order to power your house with PV cells. Silicon comes in 12 inch (300 mm) and larger wafers. Processing is cheap. But it is not a good media for microstrip (lossy), and it is not rad hard. Noise figure, power, are all second class to any of the compound semiconductors. It can only operate reliably up to 110C, but silicon is an pretty good heat dissipater.

Silicon CMOS

If you decrease the feature size of CMOS down to nanometer dimensions, you can create FETs that provide some level of performance even up to millimeterwave...

Coming soon: a discussion of silicon-on-insulator (SOI!)

Advantages: Disadvantages
Cheap! Junction temperatures should be limited to 110C

Silicon carbide LDMOS

Laterally-diffused metal oxide semiconductor technology, used to make power amps. The Freescale web site claims they pioneered the technology. Can withstand 200C channel temperatures. Good to 3 GHz, 10 watts.

Here's a separate page on silicon LDMOS!

Silicon germanium HBT

SiGe is a new development (in the last eight years), and was originally predicted to put all forms of GaAs into the history books. SiGe can make very cheap parts, with performance maybe into millimeterwave, with production processing on eight-inch (200 mm) diameters wafers. But the devices are not as high-performance as GaAs, in terms of noise figure and power. The setup charge to make a mask set is enormous, because 200 mm contact masks are needed (GaAs usually uses a 10X wafer stepper, these glass reticles are relatively cheap). You might pay $250,000 for that first SiGe wafer, but your one-millionth amplifier will be oh-so-cheap!

The poor insulating properties of a silicon substrate means it's not a good media for microstrip, so you have two choices. You can make transmission lines in the backend of line (BEOL) SiO2 and metal layers. The SiO2 dielectric layers are thin, which means high metal losses. Or you can send your wafers to a third party for post-processing to put a lower dielectric metal system on top of it, such as benzo-cyclo-butene (BCB) and gold.

Every time the upper frequency of SiGe extended, the breakdown voltage is reduced. Some of that stuff has to operate at 1.0 volts, which means forget about all but the most girly-man of power amps.

Advantages: Disadvantages
  • Eight inch silicon wafers mean low production cost in high volume
  • All-optical process (also low cost)
  • Possible to add scads of logic onto RF chip (BiCMOS logic)
  • Low Vbr, as bad as 1.5 volts for IBM "9HP"
  • Electrically, Si is not a great insulator
  • Thermal runaway?
  • 110C max junction temperature
  • Not radiation hard
  • No equivalent of a switch FET, so phase shifters and attenuators are a problem
  • Not many foundries do SiGe
  • High setup charges due to expensive mask set

Here is some info from IBM on their SiGe processes which continue to evolve. Notice they don't tell you the operating voltage continues to drop with frequency...

IBM's SiGe HBT BiCMOS Technology Generations:

- 1st Generation (IBM 5HP 50 GHz HBT + 0.35µm CMOS)

- 2nd Generation (IBM 6HP 50 GHz HBT + 0.25µm CMOS)

- 3rd Generation (IBM 7HP 120 GHz HBT + 0.18µm CMOS)

- 4th Generation (IBM 8HP 200 GHz HBT + 130µm CMOS)

- 5th Generation (IBM 9? 350 GHz HBT) so far this platform is only a rumor!

Examples:

IBM, Jazz
